SANT Cast Iron Y-Type Strainer (Screwed, IBR Approved)
By Sant ValvesIBR Approved
IBR-approved screwed cast iron Y-type strainer with an SS304 1.2 mm screen and bolted cover, protecting steam-line valves and traps up to 13 Kg/cm²g at 220°C.
Specifications
- Pattern type
- Y-Type
- Body material
- Cast Iron IBR 86 to 93 Gr.A
- Cover design
- Bolted Cover
- Trim
- SS 304 Screen, 1.2 mm dia perforation
- End connection
- Female BSP Parallel threads to BS 21
- Test pressure
- 26 Kg/cm²g (370 Psig) Hyd.
- Working pressure
- Max BOP 13 Kg/cm²g (185 Psig) at 220°C
- Application
- Steam
Overview
The SANT cast iron Y-type strainer features a robust bolted cover and a screwed end design (Female BSP parallel threads to BS 21). Engineered specifically for steam applications, it incorporates a 1.2 mm perforated SS 304 screen to effectively trap debris. The valve operates at a maximum working pressure of 13 Kg/cm²g at 220°C and is tested to 26 Kg/cm²g. It is IBR certified, ensuring compliance with rigorous boiler regulations for steam distribution. Supplied, sized and serviced for steam systems across Nepal.
Features & Benefits
- Protects critical downstream components (pumps, steam traps, control valves) from scale, dirt, and foreign debris in steam lines.
- Bolted cover allows secure sealing and safe access to the strainer screen for maintenance without removing the unit from the piping.
- 1.2 mm SS 304 perforated screen provides an optimal surface area to minimize pressure drop while effectively capturing fine particulates.
- IBR certification guarantees material traceability and safe operation in high-pressure, regulated steam systems.
- Incorporated drain plug (in sizes 25mm and above) facilitates inline blowdown of accumulated sludge without requiring full system depressurization.
- Cast Iron IBR Gr.A construction ensures structural rigidity and thermal stability at continuous operating temperatures up to 220°C.
Dimensions
All dimensions in mm
| Size (mm) | Size (inch) | F |
|---|---|---|
| 15 | 1/2" | 76 |
| 20 | 3/4" | 98 |
| 25 | 1" | 133 |
| 32 | 1.1/4" | 133 |
| 40 | 1.1/2" | 178 |
| 50 | 2" | 222 |
- All dimensions are in mm (F ±2).
- Product images are for illustration purposes only. Actual product may vary.
Materials of Construction
All dimensions in
| Component | Material | Specification |
|---|---|---|
| Body, Bonnet | Cast Iron | IBR 86 to 93 Gr.A |
| Drain Plug for 25mm & above | Bronze / SS | IBR 282(a)(iv) Gr.B / AISI410 |
| Strainer | S.S. | AISI-304 |
| Gasket | Compressed Asbestos Fibre | IS:2712 Gr.C |
| Fasteners | Mild Steel | --- |
