Cast Iron Horizontal Check Valve Flanged (Model CI-3A)
IBR-approved straight-pattern cast iron horizontal check valve to BS:5153 for PN 16 service, with a bolted cover, renewable seat and disc, and DIN 2533 RF flanged ends for steam and water up to 220°C.
Specifications
- Model
- CI-3A
- Product standard
- BS:5153
- Pattern type
- Straight Type
- Pressure class
- PN 16
- Body material
- Cast Iron IBR 86 to 93 Gr.A
- Cover type
- Bolted Cover
- Seat type
- Renewable Seat
- Disc type
- Renewable Disc
- Trim
- SS AISI-410
- End connection
- Flanges as per DIN 2533 RF (PN 16) Undrilled
- Body test pressure
- 26 Kg/cm²g (Hyd.)
- Seat test pressure
- 16 Kg/cm²g (Hyd.)
- Maximum working pressure
- Max BOP 13 Kg/cm²g at 220°C Steam
- Maximum working temperature
- 220°C
- HSN code
- 84813000
Overview
Industrial-grade cast iron horizontal check valve engineered for medium-pressure steam and water applications up to 220°C. Constructed with an IBR 86 to 93 Gr.A cast iron body in a straight pattern, featuring a bolted cover for internal access. Internal dynamic sealing is achieved through a renewable seat and disc utilizing AISI-410 stainless steel trim. Designed in compliance with BS:5153 standards, this unit supports a PN 16 pressure rating and connects via DIN 2533 RF flanged ends. Supplied, sized and serviced for steam and water pipelines across Nepal.
Features & Benefits
- Compliance with BS:5153 and explicit IBR certification ensures the valve's material traceability and hydrostatic integrity for steam generation and boiler feedwater pipelines.
- Renewable AISI-410 stainless steel seat and disc elements isolate high-wear components from the main body, significantly dropping total lifecycle cost by permitting in-line repair instead of full unit replacement.
- Bolted cover architecture grants maintenance crews direct overhead access to internals, expediting debris clearance or trim inspection without breaking flange joints.
- The straight-pattern cast iron (IBR Gr.A) body is optimized for horizontal pipeline installations, minimizing flow turbulence and resulting pressure drop across the valve.
- DIN 2533 RF standard flanges (PN 16) guarantee standardized structural mating dimensions, mitigating flange face distortion under thermal gradients typical in 220°C steam service.
Dimensions
| Size (mm) | Size (inch) | F | H (Approx.) |
|---|---|---|---|
| 15 | 1/2" | 130±1 | 70 |
| 20 | 3/4" | 150±1 | 70 |
| 25 | 1" | 160±1 | 80 |
| 32 | 1.1/4" | 180±1 | 95 |
| 40 | 1.1/2" | 200±1 | 100 |
| 50 | 2" | 230±2 | 110 |
| 65 | 2.1/2" | 290±2 | 130 |
| 80 | 3" | 310±2 | 150 |
| 100 | 4" | 350±2 | 160 |
| 125 | 5" | 400±3 | 200 |
| 150 | 6" | 480±3 | 215 |
| 200 | 8" | 600±3 | 250 |
- Product images are for illustration purposes only. Actual product may vary.
- Actual dimensions may change over time, due to continual design improvements. Please confirm before placing order.
Materials of Construction
| Component | Material | Specification |
|---|---|---|
| Body, Bonnet, Valve Disc | Cast Iron | IBR 86 to 93 Gr.A |
| Body Seat Ring, Valve Disc Ring | Stainless Steel | AISI-410 |
| Gasket | Compressed Asbestos Fiber | IS:2712 Gr.C |
| Fasteners | Mild Steel | --- |
