SANT Cast Steel Moisture Separator (Model CS-13)
Cast carbon steel moisture separator that strips entrained water from steam and gas to prevent water hammer and protect turbines and control valves, with a flanged body tested to 40 kg/cm².
Specifications
- Model
- CS-13
- Body material
- CCS (ASTM A-216 Gr. WCB)
- End connection
- Flanges as per BS10 Table F
- Body test pressure
- 40 kg/cm² Hyd.
- Maximum working pressure
- 20 kg/cm²
- HSN code
- 84818030
Overview
The SANT Cast Steel Moisture Separator (CS-13) is engineered to extract suspended water droplets and entrained moisture from steam or gas systems. Constructed with a Cast Carbon Steel (ASTM A216 Gr. WCB) body and featuring BS10 Table F flanged end connections, it is designed for heavy-duty industrial applications. The unit incorporates an AISI-410 stainless steel drain plug for condensate evacuation and utilizes a compressed asbestos fiber gasket for reliable sealing under thermal stress. The body is hydrostatically tested to 40 kg/cm². Supplied, sized and serviced for steam systems across Nepal.
Features & Benefits
- Effectively removes entrained moisture from steam lines, mitigating the risk of water hammer and protecting downstream equipment like turbines and control valves from erosion.
- Cast Carbon Steel (WCB) body provides high tensile strength and structural integrity for elevated pressure applications compared to standard cast iron variants.
- BS10 Table F flanged ends ensure a rigid, leak-tight integration into existing heavy-duty piping infrastructure.
- AISI-410 stainless steel drain plug offers corrosion-resistant access for periodic blowdown or direct integration with automated steam trap stations.
- Hydrostatic body testing at 40 kg/cm² guarantees a high safety margin against operational pressure spikes.
Dimensions
| Size (mm) | Size (inch) | F |
|---|---|---|
| 25 | 1" | 300±2 |
| 40 | 1.1/2" | 370±2 |
| 50 | 2" | 466±2 |
| 65 | 2.1/2" | 485±2 |
| 80 | 3" | 485±2 |
| 100 | 4" | 696±2 |
- All dimensions are in mm.
- Product images are for illustration purposes only. Actual product may vary.
- Actual dimensions may change over time, due to continual design improvements. Please confirm before placing order.
Materials of Construction
| Component | Material | Specification |
|---|---|---|
| Body | C.C.S. | ASTM A216 Gr. WCB |
| Gasket | Compressed Asbestos Fiber | --- |
| Drain Plug | S.S. | AISI-410 |
