Gas/Liquid Separation System - Moisture Separator
By Darling Muesco
Carbon steel moisture separator that strips entrained water from saturated steam to deliver dry steam and protect downstream equipment from water hammer.
Specifications
- Size range
- 1" (25 mm) – 8" (200 mm)
- Body material
- Carbon steel
- End connection
- Flanged
- Function
- Water particle removal from steam
- Requirement
- Steam trap for condensate discharge
- Applications
- Steam distribution, steam-driven machinery, boiler downstream pipelines
Overview
A carbon steel moisture separator designed to remove entrained water particles from saturated steam, converting it to dry steam for downstream process equipment. Works in tandem with a steam trap that collects and discharges the separated condensate. Improves thermal efficiency of steam-driven machinery by eliminating the performance losses caused by wet steam. Supplied, sized and serviced for steam systems across Nepal.
Features & Benefits
- Converts saturated steam to dry steam at the point of use, which directly recovers thermal efficiency lost when wet steam enters turbines, heat exchangers, or process equipment.
- Removing entrained moisture prevents water hammer in steam lines, which is one of the leading causes of pipeline fitting failures and valve seat erosion in steam distribution systems.
- Dry steam carries more usable latent heat per kilogram than wet steam, so downstream equipment achieves a higher heat transfer rate without increasing boiler output or fuel consumption.
- Flanged end connection across the full 25mm to 200mm size range integrates directly into standard piping systems and allows removal for inspection without cutting the line.
- Carbon steel construction handles the pressure and temperature conditions typical of industrial steam systems while keeping material cost low compared to stainless alternatives.
- Pairing with a steam trap for condensate discharge keeps the separator self-draining and prevents re-entrainment of separated water back into the steam flow.
