2/2-Way High Temperature Flanged Solenoid Valve
By ME Engineering Pvt. Ltd.CE Approved
Electrically actuated 2/2 way semi-lift diaphragm solenoid valve with flanged ends for high-volume, low-pressure switching of air, gas, water, vacuum and corrosive fluids up to 180°C, in flameproof normally open or normally closed builds.
Specifications
- Size range
- 3/8" – 4" flanged, 150#
- Temperature
- 180°C max (high temperature on request)
- Working pressure
- 0 – 5 bar max (0 – 6 bar on request)
- End connection
- Flanged 150#
- Flange drilling
- As per 150#
- Body material
- CF8, CF3M, CF8M
- Seat material
- PTFE, Viton
- Configuration
- 2/2 way
- Body style
- Flameproof, normally open and normally closed
- Media
- Oil plants, vacuum plant, pump seal, water
Overview
An electrically actuated 2/2 way semi-lift diaphragm type solenoid valve with a flanged end connection, designed for high-volume, low-pressure switching in air, gas, water, vacuum, light oil, and corrosive fluid service up to 180°C. Available in flameproof normally open and normally closed configurations, with robust flanged fittings suited to demanding industrial installation. Supplied, sized and serviced across Nepal.
Features & Benefits
- Flanged end connection gives a more secure, vibration-resistant joint than a screwed connection, which matters at the larger end of the 3/8 to 4 inch range where thread engagement alone would be a weaker mechanical joint.
- Flameproof body rating allows this valve to be installed in hazardous, potentially explosive atmospheres where a standard solenoid coil enclosure would not be permitted.
- Semi-lift diaphragm mechanism delivers high flow volume at low pressure, the same core advantage as its screwed sibling, but in a connection style suited to larger or higher-vibration installations.
- Normally open and normally closed variants let the fail-safe state be specified at order time to match the process safety requirement without custom engineering.
- PTFE and Viton seat options extend service life in corrosive fluid and light oil applications where standard elastomer seats would degrade quickly.
- Flanged installation simplifies removal for maintenance on larger valve sizes, where unscrewing a heavy threaded body in place would be impractical.
- Electric actuation with fast switching response suits automated batch or sequence control where consistent, repeatable timing matters.
Dimensions
All dimensions in mm
| Model | Size | L (SE) | B | C | D |
|---|---|---|---|---|---|
| GTD-10 | 10 mm (3/8") | 65.5 | 16 | 112 | 57 |
| GTD-15 | 15 mm (1/2") | 65.5 | 16 | 112 | 57 |
| GTD-20 | 20 mm (3/4") | 80 | 21 | 113 | 67 |
| GTD-25 | 25 mm (1") | 97 | 29 | 121 | 82 |
| GTD-40 | 40 mm (1.1/2") | 119 | 35 | 132 | 99 |
| GTD-50 | 50 mm (2") | 137 | 43 | 146 | 120 |
| GTD-65 | 65 mm (2.1/2") | 172 | 56 | 166.5 | 143 |
| GTD-80 | 80 mm (3") | 195 | 57 | 166 | 185 |
| GTD-100 | 100 mm (4") | 300 | 79 | 195 | 215.5 |
- All dimensions are in mm.
- Dimensions shown here are for indicative purposes only. Please contact our representative for exact dimensions.
